Display & Optical Specifications
| Feature |
Specification |
| Screen type |
TFT LCD with direct LED backlight |
| Panel life |
At least 50,000 hours |
| Tempered glass |
Mohs hardness level 9, anti-reflective |
| Diagonal |
86 |
| Resolution |
4K / Ultra HD (3840 x 2160) |
| Color rendering / Display colors |
1.07 billion |
| Brightness / Minimum brightness |
400 cd / m2 |
| Viewing angle |
(H / V) 178° / 178° |
| Contrast / Contrast ratio |
dynamic 5000:1 |
| Response time |
6.5 ms |
Touch & Interaction Specifications
| Feature |
Specification |
| Sensor type |
Infrared touch screen |
| Simultaneous touch points |
50 simultaneous touch points |
| Touch input |
Opaque objects (e.g. finger, pen, etc.) |
| Touch resolution |
32,768 x 32,768 pixels |
| Touch accuracy (mm) |
1 mm |
| Touch response time |
2.5 ms |
| Styluses included |
2 styluses |
| Stylus holder |
built-in magnetic holders |
System & Processing Architecture
| Component |
Configuration |
| Operating system |
Android 14.0 EDLA |
| Processor |
Octacore 4x A76/A73/A72 / 4x A55/A53 |
| Video card |
Mali Odin G610 MC4 / G52 MC3 |
| RAM |
minimum 16 GB |
| ROM |
minimum eMMC 256 GB |
Connectivity & Interface Ports
| Category |
Ports & Interfaces |
| Inputs |
3 x HDMI (4K@60); 1x DisplayPort; 1 x AUDIO; 1 x USB Type C; 1x MicroSD card reader |
| Outputs |
1 x HDMI (4K@60); 1 x AUDIO |
| Control |
1 x RS232, 4 x USB 3.0, 1 x USB 2.0, 2 x USB Type B Touch |
| Network interfaces |
2 x RJ-45, Ethernet (802.11ax) |
Media & Wireless Ecosystem
| Feature |
Specification |
| Built-in speakers |
2 x 20W |
| Wi-Fi |
included |
| Bluetooth Wi-Fi 6G |
included |
| Bluetooth |
version 5.3, data transmission range in open spaces |
| Camera |
50 MP with artificial intelligence, supports intelligent switching between Android and OPS |
| Microphones |
Omnidirectional, 8-channel |
Electrical & Included Accessories
| Feature |
Specification |
| IR remote control |
included |
| Power |
single-phase alternating voltage 220 V, can be used with a network adapter |
| Included |
wall mount, power code, manual |
